Specifications

• Brand : Asus
• CPU : Intel® Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors(Refer to www.asus.com for CPU support list.);
• Chipset ; Intel® Z790 Chipset
• Ethernet : 1 x Intel® 2.5Gb Ethernet, ASUS LANGuard
• USB : Rear USB (Total 12 ports):- 1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®); 7 x USB 3.2 Gen 2 ports (6 x Type-A + 1 x USB Type-C®); 4 x USB 3.2 Gen 1 ports (4 x Type-A). Front USB (Total 9 ports):- 1 x USB 3.2 Gen 2×2 connector (supports USB Type-C® with up to 30W PD Fast-charge);
• Memory Slots Support : 4 x DIMM, Max. 128GB, DDR5 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel® Extreme Memory Profile (XMP); OptiMem II.
• Internal I/O Connectors :Fan and Cooling related:- 1 x 4-pin CPU Fan header; 1 x 4-pin CPU OPT Fan header; 1 x 4-pin AIO Pump header; 5 x 4-pin Chassis Fan headers. Power related:- 1 x 24-pin Main Power connector; 2 x 8-pin +12V Power connectors. Storage related:- 5 x M.2 slots (Key M); 4 x SATA 6Gb/s ports. USB:- 1 x USB 3.2 Gen 2×2 connector (supports USB Type-C® with up to 30W PD Fast-charge); 2 x USB 3.2 Gen 1 header support additional 4 USB 3.2 Gen 1 ports; 2 x USB 2.0 headers support additional 4 USB 2.0 ports.
• Expansion Slots : Intel® 13th & 12th Gen Processors:- 1 x PCIe 5.0 x16 slot; Intel® Z790 Chipset:- 2 x PCIe 4.0 x16 slots (support x4 mode); 1 x PCIe 3.0 x1 slot. Please check the PCIe bifurcation table; on the support site (https://www.asus.com/support/FAQ/1037507/); When M.2_1 is occupied with SSD device, PCIEX16(G5) will run x8 only; To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
• Sound ; ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080:- Impedance sense for front and rear headphone outputs; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; High quality 120 dB SNR stereo playback output and 113 dB SNR recording input;
• Form Factor ; ATX Form Factor. 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
• Warranty : 2Year Warranty
