overview

Wide-angle camera: 116° (H), 60° (V);PoE (IEEE802.3af, Power-over- Ethernet);Two-way audio communication over IP networks with Echo Cancel feature;Complies with SIP standard for easy integration in every SIP capable PBXes;Complies with ONVIF standard for easy integration with any network surveillance system;

specifications

•  physical & power:Front panel: PlasticCamera.2M pixels, automatic lightingButton: 1 call buttonLight sensor: SupportInfrared sensor: SupportWiegand port: SupportRF card reader: 13. 56MHz & 125kHzRelays out: 2Inputs: 2Microphone: – 40dBSpeaker: 4Ω / 3WEthernet port: RJ45, 10/100Mbps adaptive802.3af Power- over- Ethernet
• Audio:SIP v1 (RFC2543), SIP v2 (RFC3261)Narrowband audio codec: G.711a, G.711μ, G.729Broadband audio codec: G.722DTMF: In-band, out-of-band DTMF (RFC2833),SIP InfoEcho CancellationVoice Activation DetectionComfort Noise Generator
• Video :Sensor: 1/2.7″, CMOSPixels: CIF, QCIF, VGA, 4CIF, 720pVideo codec: H.264Video resolution: up to 1280x720pMax. image transfer rate: 720p – 30fpsViewing angle: 116*(H) / 60°(V)
• Door Entry Feature: Relays controlled individually by DTMF tonesCamera permanently operationalAuto-night mode with LED illuminationWhite balance: autoMinimum illumination: 0.1LUX
• Networking & Protocol : Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
