overview

Vandal resistant body, with a flush button;Wide-angle camera: 110º (H), 58º (V);PoE (IEEE802.3af, Power-over-Ethernet);Two-way audio communication over IP networks with Echo Cancel feature;Complies with SIP standard for easy integration in every SIP capable PBXes;Complies with ONVIF standard for easy integration with any network surveillance system;

specifications

• physical & powerFront panel: Aluminum alloyCamera: 2M pixels, automatic lightingButton: 1 call buttonLight sensor: SupportInfrared sensor: SupportWiegand port: SupportRS485 port: SupportRF card reader: 13.56MHz (with NFC) & 125kHzRelays out: 2Inputs: 2Microphone: -40dBSpeaker: 4Ω / 3WEthernet port: RJ45, 10/100Mbps adaptive802.3af Power-over-Ethernet
• Audio:SIP v1 (RFC2543), SIP v2 (RFC3261)Narrowband audio codec: G.711a, G.711μ, G.729Broadband audio codec: G.722DTMF: In-band, out-of-band DTMF (RFC2833), SIP InfoEcho CancellationVoice Activation DetectionComfort Noise Generator
• Video: Sensor: 1/2.7”, CMOSPixels: CIF, QCIF, VGA, 4CIF, 720p, 1080pVideo codec: H.264Video resolution: up to 1920x1080pMax. image transfer rate: 1080p – 30fpsViewing angle: 110°(H) / 58°(V)
• Door Entry Feature :Relays controlled individually by DTMF tonesCamera permanently operationalAuto-night mode with LED illuminationWhite balance: autoMinimum illumination: 0.1LUX

Networking & Protocol :Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP
