overview

The Akuvox S560 is a SIP-based handset intercom. It supports basic intercom functions, such as intercom calling and door unlocking, and can be installed on a wall or placed on a desktop. With a compact and minimalist design, it is an ideal choice for smaller areas and serves perfectly as an extension unit.

•  physical & power:Front panel: Aluminium alloyRAM / ROM: 2GB / 8GBDisplay: 10 Inch IPS LCDScreen: 10 Inch capacitive touch screenWi-Fi: IEEE802.11 b/g/n, @2.4GHzBLE: Support BLE 4.2Camera: 1MP camera, CMOSMemory slot：1 Micro SD slotRS485 port: SupportRelays out: 2Bell in: 1IO: 8Microphone: -26dBSpeaker: Dual speakers, 4Ω / 3WEthernet ports: 1xRJ45, 10/100Mbps adaptive802.3af Power-over-Ethernet12V DC connector (if not using PoE)Tamper resistant: SupportInstallation: Wall-mounted & DesktopDimension: 251×182.5×29.75mm
• Touch Screen Display:Display Mode: Normally black, TransmissiveLCD Size: 10inch (Diagonal)Aspect Ratio: 16:10Resolution: 1280x800Contrast ratio: 900:1Luminance: 350 cd/m²Viewing Angle: 80° Left, 80° Right, 80° Upper, 80° LowerTouch Screen: Projected capacitive
• Audio: SIP v1 (RFC2543), SIP v2 (RFC3261)Narrowband audio codec: G.711a, G.711μ, G.729Broadband audio codec: G.722DTMF: In-band, out-of-band DTMF (RFC2833), SIP InfoEcho CancellationVoice Activation DetectionComfort Noise GeneratorAutomatic Gain Control
• Networking: Protocols support: IPv4, IPv6, HTTP, HTTPS, FTP, TFTP, SNMP, DNS, SNTP, RTSP, SRTP, RTP, TCP, UDP, TLS, ICMP, DHCP, ARP
